Harken 150mm Aluminum Stand-Up Block
Harken 150mm Aluminum Stand-Up Block
Sideplates are constructed of hardcoat-anodized 6061-T6 aluminum for strength and corrosion resistance. The ultralight composite bearing system (ULC) rides on a heat-treated stainless steel inner race to handle extremely high loads.
Technical Description
| Sheave Ø (mm) | 150 mm |
| Sheave Ø (in) | 5 15/16 in |
| Length (mm) | 297 mm |
| Length (in) | 11 11/16 in |
| Weight (kg) | 4.67 kg |
| Weight (lb) | 10.29 lb |
| Maximum line Ø (mm) | 25 mm |
| Maximum line Ø (in) | 1 in |
| Maximum working load (kg) | 10000 kg |
| Maximum working load (lb) | 22050 lb |
| Breaking load (kg) | 20000 kg |
| Breaking load (lb) | 44100 lb |
