Harken 57mm Aluminum Double Block Swivel
Harken 57mm Aluminum Double Block Swivel
Black Magic Air blocks are a top favorite of Big Boat performance racers and cruisers. These lightweight, free-running, powerful performers are used for sail controls that see lots of action: mainsheet, runner, halyard, and spinnaker systems. A center cage keeps Torlon roller bearings separated and parallel to reduce friction. Shackle blocks lock in two directions or swivel to keep line from twisting. Torlon is a registered trademark of Solvay Advanced Polymers L.L.C.
Technical Description
| Sheave Ø (mm) | 57 mm |
| Sheave Ø (in) | 2 1/4 in |
| Length (mm) | 132 mm |
| Length (in) | 5 3/16 in |
| Weight (g) | 336 g |
| Weight (oz) | 11.86 oz |
| Shackle pin Ø (mm) | 8 mm |
| Shackle pin Ø (in) | 5/16 in |
| Maximum line Ø (mm) | 12 mm |
| Maximum line Ø (in) | 7/16 in |
| Maximum working load (kg) | 1633 kg |
| Maximum working load (lb) | 3600 lb |
| Breaking load (kg) | 3267 kg |
| Breaking load (lb) | 7200 lb |
Harken 57mm Aluminum Double Block Swivel
Black Magic Air blocks are a top favorite of Big Boat performance racers and cruisers. These lightweight, free-running, powerful performers are used for sail controls that see lots of action: mainsheet, runner, halyard, and spinnaker systems. A center cage keeps Torlon roller bearings separated and parallel to reduce friction. Shackle blocks lock in two directions or swivel to keep line from twisting. Torlon is a registered trademark of Solvay Advanced Polymers L.L.C.
Technical Description
| Sheave Ø (mm) | 57 mm |
| Sheave Ø (in) | 2 1/4 in |
| Length (mm) | 132 mm |
| Length (in) | 5 3/16 in |
| Weight (g) | 336 g |
| Weight (oz) | 11.86 oz |
| Shackle pin Ø (mm) | 8 mm |
| Shackle pin Ø (in) | 5/16 in |
| Maximum line Ø (mm) | 12 mm |
| Maximum line Ø (in) | 7/16 in |
| Maximum working load (kg) | 1633 kg |
| Maximum working load (lb) | 3600 lb |
| Breaking load (kg) | 3267 kg |
| Breaking load (lb) | 7200 lb |
