Harken 76mm Single Midrange Block w/Becket
Harken 76mm Single Midrange Block w/Becket
Midrange blocks’ robust construction makes them ideal to handle the high loads found on medium and large offshore boats. Sheave runs exclusively on a ball bearing system for fast trim and release under any load.
Technical Description
| Sheave Ø (mm) | 76 mm |
| Sheave Ø (in) | 3 in |
| Length (mm) | 184 mm |
| Length (in) | 7 1/8 in |
| Weight (g) | 397 g |
| Weight (oz) | 14 oz |
| Maximum line Ø (mm) | 14 mm |
| Maximum line Ø (in) | 9/16 in |
| Shackle pin Ø (mm) | 8 mm |
| Shackle pin Ø (in) | 5/16 in |
| Maximum working load (kg) | 816 kg |
| Maximum working load (lb) | 1800 lb |
| Breaking load (kg) | 2268 kg |
| Breaking load (lb) | 5000 lb |
