Harken Performa Alum 30 Plain Top Winch - AL/2 Speed
Harken Performa Alum 30 Plain Top Winch - AL/2 Speed
The new Performa 30.2 plain top winch is Harken's smallest two-speed winch. It was originally designed to meet the power requirements of the increasingly powerful Mini Transat 6.5 fleet. This version will replace our 32.2A winches which relied on previous generation engineering aboard boats like the J80.
Technical Description
| Configuration | Plain-top |
| Speed | 2 |
| Drum Ø (mm) | 73 mm |
| Drum Ø (in) | 2 7/8 in |
| Base Ø (mm) | 120 mm |
| Base Ø (in) | 4 3/4 in |
| Line entry height (mm) | 59 mm |
| Line entry height (in) | 2 3/10 in |
| Minimum line Ø (mm) | 6 mm |
| Maximum line Ø (mm) | 10 mm |
| Fastener circle (in) | 4 in |
| Fastener circle (mm) | 100 mm |
| Fasteners (mm) | M6 SH mm |
| Fasteners (in) | 1/4 SH in |
| Number of fasteners | 5 |
| Gear ratio - 1 | 1.1 |
| Gear ratio - 2 | 4.25 |
| Power ratio - 1 | 7.8 |
| Power ratio - 2 | 29.8 |
