Nodus Deck organiser - Pad-FrD 14
Deck organiser - Pad-FrD 14Ā
| Technical Description | |||||||
| Product Name | Breaking Load | Ć A | Ć B | Ć C | Ć D | Ć Recomended Rope | Weight |
| Pad SX | gluing 200 kgĀ Ā Ā | Ā | Ā | Ā | Ā | Ā | Ā |
| Ring Duralumin | mm | mm | mm | mm | Halyard / Sheet | gr | |
| FrDĀ 10 | 7 | 12 | 12 | 30 | 8 mm max. | 8 | |
| FrDĀ 14 | 10 | 16 | 16 | 40 | 12 mm max. | 16 | |
Ā
Pad FrDĀ®, textile padlock / trigger guard with Duralumin friction ring.
Easy, fast and very simple to install, your Pad-FrDĀ®, will support up to 200 kg (without screws) once fixed with Nodus-LocĀ® bi-component glue.
Its oval shape allows the Pad-FrDĀ® to be installed in an optimal way according to the angle and the direction of the load.
- Multi-purpose textile chainplate and FrDĀ® friction ring perfect for organizing sheets, lines, etc.
- Easily installed anywhere on deck, mast or boom
Advantages
- Ready to use product
- Easy to install, thanks to our bi-component adhesive
- Optimized ergonomics, no protruding or aggressive parts
- Versatility and flexibility whatever the angle of traction
- Reliable and maintenance free
